What do you do when you’re hungry and there is no way to cook food? Definitely, you rely on a food delivery application. Have you ever wondered how this delivery process works? Well, let me walk you through the process of how Conductor helps in orchestrating the delivery process.
In this article, you will learn how to build a delivery workflow using Conductor, an open-source microservice and workflow orchestration framework. Conductor handles the process as a workflow that divides the delivery process into individual blocks. Let’s see this in action now!
Delivery Workflow
Consider that we get a request in the delivery app to send a package from an origin to a destination. The application has the details of both the registered clients and riders. It should connect the best-fitting rider to deliver the package. So, the application gets the registered riders list, picks the nearest riders, and lets them compete to win the ride.
Looks simple? Yeah! Conductor comes into action here! You can simply build your delivery application by connecting small blocks together using Conductor.
What you need!
- A list of registered riders.
- A way to let our riders know they have a possible delivery.
- A method for our riders to compete or be the first to select the ride.
Building the application
Let’s begin to bake our delivery app. Initially, we need to get some API calls for processes such as getting the riders list, notifying the riders, etc. We will make use of the dummy JSON that provides us with fake APIs.
So, in this case, we will use the user API for pulling our registered riders, and for notifying the rider about a possible ride, we will use the posts API.
Since we are creating this workflow as code, instead of using the workflow diagram, let's try to start with the test and build our workflow app from scratch. For the demonstration purpose, we will be using Orkes Playground, a free Conductor platform. However, the process would be the same for Netflix Conductor.
Workflow as Code
Project Setup
First, you need to set up a project:
- Create an npm project with
npm init and install the SDK with npm i @io-orkes/conductor-javascript. - You'll need to add jest and typescript support. For this, copy and paste the jest.config.js and tsconfig.json files into your project in the root folder. Then add the following devDependencies as a separate JSON file:
"scripts": {
"test": "jest"
},
"devDependencies": {
"@tsconfig/node16": "^1.0.2",
"@types/jest": "^29.0.3",
"@types/node": "^17.0.30",
"@types/node-fetch": "^2.6.1",
"@typescript-eslint/eslint-plugin": "^5.23.0",
"@typescript-eslint/parser": "^5.23.0",
"eslint": "^6.1.0",
"jest": "^28.1.0",
"ts-jest": "^28.0.1",
"ts-node": "^10.7.0",
"typescript": "^4.6.4"
},
- Run
yarn to fetch them.
So, now you’ve created your project. As we are creating the workflow as code, next, let's create two files; mydelivery.ts and mydelivery.test.ts. By writing our code along with the test, you will get instant feedback and know exactly what happens with every step.
Creating Our Workflow
Let’s begin creating our workflow. Initially, we need to calculate the distance between the two points, i.e., the rider and the package to be delivered. We leverage this distance to calculate the shipment cost too. So let's create a workflow that can be reused in both situations.
Let the first workflow be calculate_distance that outputs the result of some function. So in our mydelivery.ts, let's update the following code:
import {
generate,
TaskType,
OrkesApiConfig,
} from "@io-orkes/conductor-javascript";
export const playConfig: Partial<OrkesApiConfig> = {
keyId: "your_key_id",
keySecret: "your_key_secret",
serverUrl: "https://play.orkes.io/api",
};
export const calculateDistanceWF = generate({
name: "calculate_distance",
inputParameters: ["origin", "destination"],
tasks: [
{
type: TaskType.INLINE,
name: "calculate_distance",
inputParameters: {
expression: "12",
},
},
],
outputParameters: {
distance: "${calculate_distance_ref.output.result}",
identity: "${workflow.input.identity}",
},
});
Now in our test file, create a test that generates the workflow so we can look at it later on the Playground.
import {
orkesConductorClient,
WorkflowExecutor,
} from "@io-orkes/conductor-javascript";
import { calculateDistanceWF, playConfig } from "./mydelivery";
describe("My Delivery Test", () => {
const clientPromise = orkesConductorClient(playConfig);
describe("Calculate distance workflow", () => {
test("Creates a workflow", async () => {
const client = await clientPromise;
const workflowExecutor = new WorkflowExecutor(client);
await expect(
workflowExecutor.registerWorkflow(true, calculateDistanceWF)
).resolves.not.toThrowError();
console.log(JSON.stringify(calculateDistanceWF, null, 2));
});
});
});
Now, run npm test.
We have just created our first workflow, which basically prints the output of its task. If you look at the generated JSON, you'll notice that there are some additional attributes apart from the ones we’ve given as inputs. That's because the generate function will generate default values, which you can overwrite later. You'll also notice that I’ve called this "${calculate_distance_ref.output.distance}" using the generated task reference name. If you don't specify a taskReferenceName, it will generate one by adding _ref to the specified name. To reference a task output or a given task, we always use the taskReferenceName. Another thing to notice is the true value passed as the first argument of the registerWorkflow function. This flag specifies that the workflow will be overwritten, which is required since we will run our tests repeatedly.
Let's create a test to actually run the workflow now. You can add the origin and destination parameters previously known by the workflow definition (Workflow input parameters). We are not using it for now, but it is relevant in the further steps.
test("Should calculate distance", async () => {
const origin = {
latitude: -34.4810097,
longitude: -58.4972602,
};
const destination = {
latitude: -34.4810097,
longitude: -58.491168,
};
const client = await clientPromise;
const workflowExecutor = new WorkflowExecutor(client);
const executionId = await workflowExecutor.startWorkflow({
name: calculateDistanceWF.name,
version: 1,
input: {
origin,
destination,
},
});
const workflowStatus = await workflowExecutor.getWorkflow(executionId, true);
expect(workflowStatus?.status).toEqual("COMPLETED");
expect(workflowStatus?.output?.distance).toBe(12);
});
Now, run yarn test, and great, we have our first workflow execution run!
Calculating Actual Distance
Next, we need to calculate the actual or approximate distance between the two points. To get the distance between two points in a sphere, we could use the Haversine formula, but since we don't want a direct distance (because our riders can't fly :P), we will implement something like Taxicab geometry.
Calculating distance using an INLINE Task
An INLINE task can be utilized in situations where the code is required to be simple. The INLINE task can take input parameters and an expression. If we go back to our calculate_distance workflow, it takes no context and returns a hard-coded object. Now, let’s modify our inline task to take the origin and destination to calculate the approximate distance.
export const calculateDistanceWF = generate({
name: "calculate_distance",
inputParameters: ["origin", "destination"],
tasks: [
{
name: "calculate_distance",
type: TaskType.INLINE,
inputParameters: {
fromLatitude: "${workflow.input.from.latitude}",
fromLongitude: "${workflow.input.from.longitude}",
toLatitude: "${workflow.input.to.latitude}",
toLongitude: "${workflow.input.to.longitude}",
expression: function ($: any) {
return function () {
function degreesToRadians(degrees: any) {
return (degrees * Math.PI) / 180;
}
function harvisineManhatam(elem: any) {
var EARTH_RADIUS = 6371;
var a = Math.pow(Math.sin(elem / 2), 2);
var c = 2 * Math.atan2(Math.sqrt(a), Math.sqrt(1 - a));
return EARTH_RADIUS * c;
}
var deltaLatitude = Math.abs(
degreesToRadians($.fromLatitude) - degreesToRadians($.toLatitude)
);
var deltaLongitude = Math.abs(
degreesToRadians($.fromLongitude) -
degreesToRadians($.toLongitude)
);
var latitudeDistance = harvisineManhatam(deltaLatitude);
var longitudeDistance = harvisineManhatam(deltaLongitude);
return Math.abs(latitudeDistance) + Math.abs(longitudeDistance);
};
},
},
},
],
outputParameters: {
distance: "${calculate_distance_ref.output.result}",
},
});
If we run the test, it will fail because the result is not 12; i.e., in the workflow calculate_distance, the input parameter was defined as 12.
But in accordance with Red-Green-Refactor, we can calculate the distance using Taxicab geometry if we pick the two cardinal points. So this test should pass. So let’s decide the origin and destination points to be the same, so the result is 0. It is actually .toEqual(0) since it’s returning an object. So we can fix that in the test.
Note: Key takeaway from the above case: I’ve used ES5 javascript on my editor and not as a string. However, you can't use closures with the rest of the file’s code, and the returned function has to be written in ES5. Else the tests will fail.
Running the test now registers a new workflow overwriting the old one.
Finding Best Rider
Now that we have the calculate_distance workflow. We can think of this workflow as a function that can later be invoked into a different project/file.
And let's create workflow number two, i.e.,findNearByRiders, which will hit a microservice that pulls the registered riders list.
Hitting Microservice
We can use the HTTP task to hit something simple as an HTTP microservice. The HTTP task will take some input parameters and hit an endpoint with our configuration. It is similar to cURL or Postman. We will be using dummy json, which returns a list of users with an address. Preferably, consider this address as the last reported address from the riders.
export const nearByRiders = generate({
name: "findNearByRiders",
tasks: [
{
type: TaskType.HTTP,
name: "get_users",
taskReferenceName: "get_users_ref",
inputParameters: {
http_request: {
uri: "http://dummyjson.com/users",
method: "GET",
},
},
},
],
outputParameters: {
possibleRiders: "${get_users_ref.output.response.body.users}",
},
});
Our findNearByRiders workflow hits an endpoint and returns the list of all available riders.
Let's write the test.
describe("NearbyRiders", () => {
test("Creates a workflow", async () => {
const client = await clientPromise;
const workflowExecutor = new WorkflowExecutor(client);
await expect(
workflowExecutor.registerWorkflow(true, nearByRiders)
).resolves.not.toThrowError();
});
test("Should return all users with latest reported address", async () => {
const client = await clientPromise;
const workflowExecutor = new WorkflowExecutor(client);
const executionId = await workflowExecutor.startWorkflow({
name: nearByRiders.name,
input: {
place: {
latitude: -34.4810097,
longitude: -58.4972602,
},
},
version: 1,
});
await new Promise((r) => setTimeout(() => r(true), 2000));
const workflowStatus = await client.workflowResource.getExecutionStatus(
executionId,
true
);
expect(workflowStatus.status).toBe("COMPLETED");
expect(workflowStatus?.output?.possibleRiders.length).toBeGreaterThan(0);
console.log("Riders", JSON.stringify(workflowStatus?.output, null, 2));
});
});
If we run our test, it should pass since the number of users is around 30. Looking at the printed output, you can see that the whole structure is being returned by the endpoint.
Our workflow is incomplete because it only returns the list of every possible rider. But we need to get the distance between the riders and the packages. For this, we must run our previous workflow calculate_distance for every rider on the fetched list. Let’s prepare the data to be passed to the next workflow. Here, we utilize the JQ Transform task, which runs a JQ query over the JSON data.
Let's add the JQ task.
export const nearByRiders = generate({
name: "findNearByRiders",
tasks: [
{
type: TaskType.HTTP,
name: "get_users",
taskReferenceName: "get_users_ref",
inputParameters: {
http_request: {
uri: "http://dummyjson.com/users",
method: "GET",
},
},
},
{
type: TaskType.JSON_JQ_TRANSFORM,
name: "summarize",
inputParameters: {
users: "${get_users_ref.output.response.body.users}",
queryExpression:
".users | map({identity:{id,email}, to:{latitude:.address.coordinates.lat, longitude:.address.coordinates.lng}} + {from:{latitude:${workflow.input.place.latitude},longitude:${workflow.input.place.latitude}}})",
},
},
],
outputParameters: {
possibleRiders: "${get_users_ref.output.response.body.users}",
},
});
From the task definition here, you can see the mapping of JQ users to the variable output of the HTTP task and then extracting the address. The expected result should have the structure {identity:{id,email}, to:{latitude,longitude}, from:{latitude,longitude}}.
Dot Map method
At this point, we have an array with all possible riders and a workflow to calculate the distance between two points. We must aggregate these to calculate the distance between the package and the riders so that the nearby riders can be chosen. While aggregating in javascript or changing the data for every item in the array, we usually leverage the map method, which takes a function that will be applied to every item in the array.
Since we extracted the distance calculated, and need to map our riders through a “function”. Let’s create a dot map workflow for this. This workflow takes the array of riders as the input parameters and the workflow ID of the calculate_distance to run on each rider.
Note that this new workflow will work for every array and workflow ID provided and is not limited to the riders and the calculate_distance workflow.
describe("Mapper Test", () => {
test("Creates a workflow", async () => {
const client = await clientPromise;
await expect(
client.metadataResource.create(workflowDotMap, true)
).resolves.not.toThrowError();
});
test("Gets existing workflow", async () => {
const client = await clientPromise;
const wf = await client.metadataResource.get(workflowDotMap.name);
expect(wf.name).toEqual(workflowDotMap.name);
expect(wf.version).toEqual(workflowDotMap.version);
});
test("Can map over an array using a workflow", async () => {
const client = await clientPromise;
const workflowExecutor = new WorkflowExecutor(client);
const from = {
latitude: -34.4810097,
longitude: -58.4972602,
};
const to = {
latitude: -34.494858,
longitude: -58.491168,
};
const executionId = await workflowExecutor.startWorkflow({
name: workflowDotMap.name,
version: 1,
input: {
inputArray: [{ from, to, identity: "js@js.com" }],
mapperWorkflowId: "calculate_distance",
},
});
await new Promise((r) => setTimeout(() => r(true), 1300));
const workflowStatus = await client.workflowResource.getExecutionStatus(
executionId,
true
);
expect(workflowStatus?.status).toBe("COMPLETED");
expect(workflowStatus?.output?.outputArray).toEqual(
expect.arrayContaining([
expect.objectContaining({
distance: 2.2172824347556963,
}),
])
);
});
});
Workflow
export const workflowDotMap = generate({
name: "workflowDotMap",
inputParameters: ["inputArray", "mapperWorkflowId"],
tasks: [
{
type: TaskType.JSON_JQ_TRANSFORM,
name: "count",
taskReferenceName: "count_ref",
inputParameters: {
input: "${workflow.input.inputArray}",
queryExpression: ".[] | length",
},
},
{
type: TaskType.JSON_JQ_TRANSFORM,
name: "dyn_task_builder",
taskReferenceName: "dyn_task_builder_ref",
inputParameters: {
input: {},
queryExpression:
'reduce range(0,${count_ref.output.result}) as $f (.; .dynamicTasks[$f].subWorkflowParam.name = "${workflow.input.mapperWorkflowId}" | .dynamicTasks[$f].taskReferenceName = "mapperWorkflow_wf_ref_\\($f)" | .dynamicTasks[$f].type = "SUB_WORKFLOW")',
},
},
{
type: TaskType.JSON_JQ_TRANSFORM,
name: "dyn_input_params_builder",
taskReferenceName: "dyn_input_params_builder_ref",
inputParameters: {
taskList: "${dyn_task_builder_ref.output.result}",
input: "${workflow.input.inputArray}",
queryExpression:
'reduce range(0,${count_ref.output.result}) as $f (.; .dynamicTasksInput."mapperWorkflow_wf_ref_\\($f)" = .input[$f])',
},
},
{
type: TaskType.FORK_JOIN_DYNAMIC,
inputParameters: {
dynamicTasks: "${dyn_task_builder_ref.output.result.dynamicTasks}",
dynamicTasksInput:
"${dyn_input_params_builder_ref.output.result.dynamicTasksInput}",
},
},
{
type: TaskType.JOIN,
name: "join",
taskReferenceName: "join_ref",
},
{
type: TaskType.JSON_JQ_TRANSFORM,
name: "to_array",
inputParameters: {
objValues: "${join_ref.output}",
queryExpression: ".objValues | to_entries | map(.value)",
},
},
],
outputParameters: {
outputArray: "${to_array_ref.output.result}",
},
});
- From the above example workflow, we get the number of arrays.
- At "dyn_task_builder", we create a SubWorkflow task template for every item within the array.
- At "dyn_input_params_builder", we prepare the parameters to pass on to each SubWorkflow.
- Using FORK_JOIN_DYNAMIC, we create each task using our previously created template and pass the corresponding parameters. After the join operation, use a JSON_JQ_TRANSFORM task to extract the results and return an array with the transformations.
Calculating distance between package and riders
Given that we now have the origin and destination points, let us modify the NearbyRiders workflow so that using the riders' last reported locations, we get the distance between the package and the riders. To achieve this, we pull the riders from the microservice, calculate the distance to the package and sort them by the distance from the package.
describe("NearbyRiders", () => {
test("Creates a workflow", async () => {
const client = await clientPromise;
const workflowExecutor = new WorkflowExecutor(client);
await expect(
workflowExecutor.registerWorkflow(true, nearByRiders)
).resolves.not.toThrowError();
});
test("Should return all users with latest reported address", async () => {
const client = await clientPromise;
const workflowExecutor = new WorkflowExecutor(client);
const executionId = await workflowExecutor.startWorkflow({
name: nearByRiders.name,
input: {
place: {
latitude: -34.4810097,
longitude: -58.4972602,
},
},
version: 1,
});
await new Promise((r) => setTimeout(() => r(true), 2000));
const workflowStatus = await client.workflowResource.getExecutionStatus(
executionId,
true
);
expect(workflowStatus.status).toBe("COMPLETED");
expect(workflowStatus?.output?.possibleRiders.length).toBeGreaterThan(0);
});
test("User object should contain distance to package", async () => {
const client = await clientPromise;
const workflowExecutor = new WorkflowExecutor(client);
const executionId = await workflowExecutor.startWorkflow({
name: nearByRiders.name,
input: {
place: {
latitude: -34.4810097,
longitude: -58.4972602,
},
},
version: 1,
});
await new Promise((r) => setTimeout(() => r(true), 2000));
const nearbyRidersWfResult =
await client.workflowResource.getExecutionStatus(executionId, true);
expect(nearbyRidersWfResult.status).toBe("COMPLETED");
nearbyRidersWfResult.output?.possibleRiders.forEach((re: any) => {
expect(re).toHaveProperty("distance");
expect(re).toHaveProperty("rider");
});
});
});
Workflow
export const nearByRiders = generate({
name: "findNearByRiders",
inputParameters: ["place"],
tasks: [
{
type: TaskType.HTTP,
name: "get_users",
taskReferenceName: "get_users_ref",
inputParameters: {
http_request: {
uri: "http://dummyjson.com/users",
method: "GET",
},
},
},
{
type: TaskType.JSON_JQ_TRANSFORM,
name: "summarize",
inputParameters: {
users: "${get_users_ref.output.response.body.users}",
queryExpression:
".users | map({identity:{id,email}, to:{latitude:.address.coordinates.lat, longitude:.address.coordinates.lng}} + {from:{latitude:${workflow.input.place.latitude},longitude:${workflow.input.place.latitude}}})",
},
},
{
type: TaskType.SUB_WORKFLOW,
name: "distance_to_riders",
subWorkflowParam: {
name: "workflowDotMap",
version: 1,
},
inputParameters: {
inputArray: "${summarize_ref.output.result}",
mapperWorkflowId: "calculate_distance",
},
},
{
type: TaskType.JSON_JQ_TRANSFORM,
name: "riders_picker",
taskReferenceName: "riders_picker_ref",
inputParameters: {
ridersWithDistance: "${distance_to_riders_ref.output.outputArray}",
queryExpression:
".ridersWithDistance | map( {distance:.distance, rider:.identity}) | sort_by(.distance) ",
},
},
],
outputParameters: {
possibleRiders: "${riders_picker_ref.output.result}",
},
});
This will give us a list of riders with their distance to the package, sorted by distance from the package.
Picking a Rider
Now we have all the required data, such as package origin/destination, riders, and their distance from the package.
Next, we’ll pre-select N riders, notify them of the possible ride, and ensure that a rider picks the ride. And for this last part, we will create a worker who will randomly select one.
export const createRiderRaceDefintion = (client: ConductorClient) =>
client.metadataResource.registerTaskDef([
{
name: "rider_race",
description: "Rider race",
retryCount: 3,
timeoutSeconds: 3600,
timeoutPolicy: "TIME_OUT_WF",
retryLogic: "FIXED",
retryDelaySeconds: 60,
responseTimeoutSeconds: 600,
rateLimitPerFrequency: 0,
rateLimitFrequencyInSeconds: 1,
ownerEmail: "youremail@example.com",
pollTimeoutSeconds: 3600,
},
]);
export const pickRider = generate({
name: "pickRider",
inputParameters: ["targetRiders", "maxCompetingRiders"],
tasks: [
{
name: "do_while",
taskReferenceName: "do_while_ref",
type: TaskType.DO_WHILE,
inputParameters: {
amountOfCompetingRiders: "${workflow.input.maxCompetingRiders}",
riders: "${workflow.input.targetRiders}",
},
loopCondition: "$.do_while_ref['iteration'] < $.amountOfCompetingRiders",
loopOver: [
{
taskReferenceName: "assigner_ref",
type: TaskType.INLINE,
inputParameters: {
riders: "${workflow.input.targetRiders}",
currentIteration: "${do_while_ref.output.iteration}",
expression: ($: {
riders: {
distance: number;
rider: { id: number; email: string };
}[];
currentIteration: number;
}) =>
function () {
var currentRider = $.riders[$.currentIteration - 1];
return {
distance: currentRider.distance,
riderId: currentRider.rider.id,
riderEmail: currentRider.rider.email,
};
},
},
},
{
type: TaskType.HTTP,
name: "notify_riders_of_ride",
taskReferenceName: "notify_riders_of_ride",
inputParameters: {
http_request: {
uri: "http://dummyjson.com/posts/add",
method: "POST",
body: {
title:
"Are you available to take a ride of a distance of ${assigner_ref.output.result.distance} km from you",
userId: "${assigner_ref.output.result.riderId}",
},
},
},
},
],
},
{
type: TaskType.SIMPLE,
name: "rider_race",
inputParameters: {
riders: "${workflow.input.targetRiders}",
},
},
],
outputParameters: {
selectedRider: "${rider_race_ref.output.selectedRider}",
},
});
To select the rider and notify them, we utilize the DO_WHILE task. By simulation, we let the riders know that there is a ride they will be interested in. The notifying order would be from the nearest package to the less near one. Finally, we simulate with a simple task that a rider has accepted our ride.
For this, we need to register the task initially. By doing this, we let the Conductor know that a worker will be doing the simple tasks. The actual worker needs to be set up for the scheduled tasks to be executed. Otherwise, while running the above workflow, it will be in a SCHEDULED state and wait for the worker to finish the task, which will never get picked up by a worker.
Setting up Worker
To implement the worker, we need to create an object of type RunnerArgs. The worker takes a taskDefName which should match our SIMPLE task's reference name. You may have multiple workers waiting for the same task. However, the first one to poll for work with the task name gets the job done.
export const riderRespondWorkerRunner = (client: ConductorClient) => {
const firstRidertoRespondWorker: RunnerArgs = {
taskResource: client.taskResource,
worker: {
taskDefName: "rider_race",
execute: async ({ inputData }) => {
const riders = inputData?.riders;
const [aRider] = riders.sort(() => 0.5 - Math.random());
return {
outputData: {
selectedRider: aRider.rider,
},
status: "COMPLETED",
};
},
},
options: {
pollInterval: 10,
domain: undefined,
concurrency: 1,
workerID: "",
},
};
const taskManager = new TaskRunner(firstRidertoRespondWorker);
return taskManager;
};
Workflow
describe("PickRider", () => {
test("Creates a workflow", async () => {
const client = await clientPromise;
await expect(
client.metadataResource.create(pickRider, true)
).resolves.not.toThrowError();
});
test("Every iteration should have the current driver", async () => {
const client = await clientPromise;
await createRiderRaceDefintion(client);
const runner = riderRespondWorkerRunner(client);
runner.startPolling();
const maxCompetingRiders = 5;
const targetRiders = [
{
distance: 12441.284548668005,
rider: {
id: 15,
email: "kminchelle@qq.com",
},
},
{
distance: 16211.662539905119,
rider: {
id: 8,
email: "ggude7@chron.com",
},
},
{
distance: 17435.548525470404,
rider: {
id: 29,
email: "jissetts@hostgator.com",
},
},
{
distance: 17602.325904122146,
rider: {
id: 20,
email: "aeatockj@psu.edu",
},
},
{
distance: 17823.508069312982,
rider: {
id: 3,
email: "rshawe2@51.la",
},
},
{
distance: 17824.39318092907,
rider: {
id: 7,
email: "dpettegre6@columbia.edu",
},
},
{
distance: 23472.94011516013,
rider: {
id: 26,
email: "lgronaverp@cornell.edu",
},
},
];
const workflowExecutor = new WorkflowExecutor(client);
const executionId = await workflowExecutor.startWorkflow({
name: pickRider.name,
input: {
maxCompetingRiders,
targetRiders,
},
version: 1,
});
await new Promise((r) => setTimeout(() => r(true), 2500));
const workflowStatus = await client.workflowResource.getExecutionStatus(
executionId,
true
);
expect(workflowStatus.status).toEqual("COMPLETED");
const doWhileTaskResult = workflowStatus?.tasks?.find(
({ taskType }) => taskType === TaskType.DO_WHILE
);
expect(doWhileTaskResult?.outputData?.iteration).toBe(maxCompetingRiders);
expect(workflowStatus?.output?.selectedRider).toBeTruthy();
runner.stopPolling();
});
});
Baking Delivery App - Combining blocks
Finally, we have all our ingredients ready. Now, let’s bake our delivery app together.
In a nutshell, when we have a client with a package request with the origin and destination points, we need to pick the best rider to deliver the package from the origin to the destination. As a bonus, let’s compute the delivery cost and make it less expensive if our client is paying by card instead of cash.
So, we run the nearbyRiders workflow passing the origin as an input parameter. This would give a list of possible riders, of which one would be picked based on “who answers first”. Next, we calculate the distance from the origin to the destination to compute the cost. Therefore, the workflow delivers the output with the selected rider and the shipping cost.
Workflow
export const deliveryWorkflow = generate({
name: "deliveryWorkflow",
inputParameters: ["origin", "packageDestination", "client", "paymentMethod"],
tasks: [
{
taskReferenceName: "possible_riders_ref",
type: TaskType.SUB_WORKFLOW,
subWorkflowParam: {
version: nearByRiders.version,
name: nearByRiders.name,
},
inputParameters: {
place: "${workflow.input.origin}",
},
},
{
taskReferenceName: "pick_a_rider_ref",
type: TaskType.SUB_WORKFLOW,
subWorkflowParam: {
version: pickRider.version,
name: pickRider.name,
},
inputParameters: {
targetRiders: "${possible_riders_ref.output.possibleRiders}",
maxCompetingRiders: 5,
},
},
{
taskReferenceName: "calculate_package_distance_ref",
type: TaskType.SUB_WORKFLOW,
subWorkflowParam: {
version: calculateDistanceWF.version,
name: calculateDistanceWF.name,
},
inputParameters: {
from: "${workflow.input.origin}",
to: "${workflow.input.packageDestination}",
identity: "commonPackage",
},
},
{
type: TaskType.SWITCH,
name: "compute_total_cost",
evaluatorType: "value-param",
inputParameters: {
value: "${workflow.input.paymentMethod}",
},
expression: "value",
decisionCases: {
card: [
{
type: TaskType.INLINE,
taskReferenceName: "card_price_ref",
inputParameters: {
distance: "${calculate_package_distance_ref.output.distance}",
expression: ($: { distance: number }) =>
function () {
return $.distance * 20 + 20;
},
},
},
{
type: TaskType.SET_VARIABLE,
inputParameters: {
totalPrice: "${card_price_ref.output.result}",
},
},
],
},
defaultCase: [
{
type: TaskType.INLINE,
taskReferenceName: "non_card_price_ref",
inputParameters: {
distance: "${calculate_package_distance_ref.output.distance}",
expression: ($: { distance: number }) =>
function () {
return $.distance * 40 + 20;
},
},
},
{
type: TaskType.SET_VARIABLE,
inputParameters: {
totalPrice: "${non_card_price_ref.output.result}",
},
},
],
},
],
outputParameters: {
rider: "${pick_a_rider_ref.output.selectedRider}",
totalPrice: "${workflow.variables.totalPrice}",
},
});
Wrapping Up
And our app is finally ready. Building an app this way resembles the same process as app building via coding. But here, we put together small building blocks to make a giant workflow.
Following this article along with Orkes Playground, you can seamlessly visualize the building blocks. You can make further improvements to the application by focusing on that particular block without losing the application's perspective as a whole.
[
You can test out Conductor for free in Orkes Playground, or if you’re looking for a cloud version, you may have a sneak peek at Orkes Cloud.
